Wintech PD Detector can also be compatible with "Internet of Things" & "Smart Grid"

WinTech PD detector can be controlled remotely and transmit analytical results via internet and thus it is indeed an illustration of "Internet of Things" applied in power quality monitoring.

WinTech PD detector can also be compatible with "Smart Grid" to upgrade the safety and reliability of power system.

---

PD phenomenon of GAS Insulated Switchgear

Case situation : Metal particles and protrusion | Bubble and crack on spacer | Moisture in SF6

案例狀況：金屬微粒 | 尖刺突出物 | 絕緣間隔器表面微粒、裂痕 | 濕氣影響SF6 特性

---

Installation of Sensors
Products and services：

• Initial PD Monitor by PD Detector
• Diagnostic PD Test by Wintech Power
• Compatible sensors: AE, HFCT, TEV, UHF-GIS

Suggested Instrument:

• WINTECH POWER * 1
• TEV Sensor * 1
• HFCT Sensor * 1
• AE Sensor * 1
• UHF-GIS * 1

---

PD phenomenon of Cast-Resin Transformer

Case situation : Bubble and crack in resin | Metal protrusion

案例狀況：​套管瑕疵 | 鐵心瑕疵 | 內部氣隙

---

Installation of Sensors
Products and services：

• Initial PD Monitor by PD Detector
• Diagnostic PD Test by Wintech Power
• Compatible sensors: AE, HFCT, TEV, UHF-FS, UHF Locator

Suggested Instrument：

• WINTECH POWER * 1
• TEV Sensor * 1
• HFCT Sensor * 1
• AE Sensor * 1
• UHF-FS * 1

---

PD phenomenon of Oil Immersed Transformer

Case situation : Insulating oil Deterioration｜Metal Protrusion｜Bubble in insulating oil

案例狀況：絕緣油及材料等劣化 | 線圈及鐵心瑕疵 | 油中氣泡

---

Installation of Sensors
Products and services：

• Initial PD Monitor by PD Detector
• Diagnostic PD Test by Wintech Power
• Compatible sensors:UHF-OTS x 4

Suggested Instrument：

• WINTECH POWER x 1
• TEV Sensor x 1
• HFCT Sensor x 1
• AE Sensor x 1

---

phenomenon of switchgear discharge

Case situation：Insulation Deterioration | Metal Protrusion | Cracks | Poor connection

案例狀況：絕緣劣化 | 金屬突出物 | 裂痕 | 接觸不良

---

Installation of Sensors
Suggested Instrument：

• Initial PD Monitor by PD Detector
• Diagnostic PD Test by Wintech Power
• Compatible sensors：HFCT, TEV, UHF-FS, UHF-GIS, UHF Locator

Suggested Instrument：

• WINTECH POWER x 1
• TEV Sensor x 1
• HFCT Sensor x 1
• AE Sensor x 1
• UHF-FS x 1

PD Detector on-line monitoring

---

Phenomenon of power cables discharge

Case situation：Crack | Metal Protrusion | Steam | Poor installation

案例狀況：裂隙、裂痕 | 尖端突出物 | 水氣 | 施工不良

---

​ Installation of Sensors
Products and services

• Diagnostic PD Test by Wintech Power
• Compatible sensors：HFCT, TEV, UHF-FS

Suggested Instrument for Termination

• WINTECH POWER x 1
• HFCT Sensor x 1
• UHF-FS x 1

Suggested Instrument for Joint

• WINTECH POWER x 1
• TEV Sensor x 1
• HFCT Sensor x 1
